LH500ATV-D

1-14121g34350537
1-14121g343505371-14121g343416301-14121g342431c1-14121g34404148


The large size of LH500ATV-D combined with racks in front of the wheel and behind the saddle, offers plenty of room for carrying all the necessary things and more. Whether it's daily shopping or baggage for an adventure trip, the payload of 150 kgs offers extended possibilities to the rider. Like the rest of Linhai ATVs, LH500ATV-D also features a standard hitch, increasing its capabilities to meet the needs of professionals working in the primary sector.
The 493cc single-cylinder engine gives 32.6 horsepower and 3.2 kg.m torque, delivering the necessary performance for LH500ATV-D to easily go through any terrain. This is also due to the possibility to chose for the drive to be carried on either two or four wheels, whenever the rider wishes, through a switch on the controls. The absence of the clutch actively contributes to the ease of driving, while the centrifugal transmission is short and long (L/H) as well as reverse (R) with good scaling, thus the optimum torque based on the conditions is always achieved. LH500ATV-D is available in four colors: red, blue, white and green.



Price: € 5.750

TECHNICAL SPECIFICATION LINHAI LH500ATV-D
DIMENSIONS
Total Length (mm) 2.120
Total Height(mm) 1.215
Wheel base (mm) 1.285
Ground clearance (mm) 253
Seat height (mm) 900
FRAME
Type Steel Tubular
Width (mm) 1.185
Weight (kg) 364
Payload / tensile strength (kg) 150/200
Max. Load capacity front/rear (kg) 18/36
Fuel Tank (lt) 12,5
Maximum speed (km/h) 89
ENGINE
Type 4-stroke water cooled, one cylinder, SOHC
Bore x Stroke (mm) 87,5 x 82
Displacement (cc) 493
Compression Ratio 10,2:1
Max. Power(ΗΡ/rpm) 32,6/-
Max. Torque (kg.m/rpm) 3,95/5.500
Special power (ΗΡ/l) 66,12
Fuel Supply EFI
Output system 1 to 1
Lubricating system Liquid crankcase
Start type Electric
Ignition type CDI
TRANSMISSION
Clutch
Centrifugal
Drive
4x4 or 2x4
REAR
SUSPENSION
Two shock absorbers
Settings Spring Preloaded, Oil Damping
WHEEL
Tire
ΑΤ24x10-12
Tire Pressure(kPa) 95
BRAKE
One Disc
FRONT
SUSPENSION
McPherson Independent suspension
Settings Spring Preloaded, Oil Damping
WHEEL
Tire ΑΤ25x8-12
Tire Pressure(kPa) 95
BRAKE
Two Discs

24310 20845
