LH400U UTV

1-14121z95501915

1-14121z95501915

1-14121z95430d5

1-14121z954095d

1-14121z9553v60

Overview

LINHAI UTV 400U DISPLACEMENT: 352cc
SINGLE CYLINDER, WATER COOLING, 4 STROKE, SOHC
MAX POWER: 20hp
FRONT SUSPENSION: Macphersan
REAR SUSPENSION: TWIN A-ARM INDEPENDENT
CLEARANCE: 170mm /285mm (utv400-2)
FUEL TANK CAPACITY: 26L
BRAKE SYSTEM: Hydraulic

Specifications

Vehicle	Model	LH400CUV
	Length×Width×Height	2683×1460×1890 mm
	Wheelbase	1805mm
	Seat height	850mm
	Mini Ground Clearance	170mm
	Mini Turning Diameter	4500mm
	Fuel Capacity	26L
	Weight	516kg
	Payload Capacity	300kg
	Drive	Switchable 2WD/4WD
Engine	Type No.	LH180MQ
Classis	Brake	Hydraulic
	Suspension	Front: McPherson independent suspension；Rear: Twin-A arm independent suspension
	Shock Absorber	Spring Preloaded,Oil Damping
	Rim	Front: AT25X8-12 Rear: AT25X10-12
	Tire Pressure(kpa)	Front:35kPa;Rear: 35kPa
Certificate		EEC/EPA
Color(s) Available		RED,GREEN,WHITE，CAMO，VISTA CAMO
Loading QTY. of 40'HC		18

Engine

Type No.	LH180MQ
Model	One Cylinder、4-Stroke、Water and Oil Cooling, SOHC
Displacement	352cc
Bore and Stroke	80×70 mm
Compression Ratio	9.8:1
Max torque and REV	27Nm/5500(r/min)
Max Output Power	19Kw/7000-7500(r/min)
Max Speed	68km/h
Start Type	Electric
Ignition Type	TCI
Transmission	CVT
