Overview

LINHAI UTV 800U-2D Diesel DISPLACEMENT: 762cc
3 CYLINDERS, 4 CYCLE, INLINE, WATER-COOLED DIESEL
MAX POWER: 40.8hp/19.72
FRONT SUSPENSION: DUAL A-ARM
REAR SUSPENSION: INDEPENDENT (IRS)
FUEL TANK CAPACITY: 35L
BRAKE SYSTEM: Hydraulic
TOWING CAPACITY: 680kg

Specifications

Vehicle	Length×Width×Height	3018×1520×1905 mm
	Wheelbase	1930mm
	Mini Ground Clearance	11in/280mm
	Unladen Weight	1543lbs/700kg
	Cargo Box Capacity	882lbs/400kg
	Towing Capacity	1499lbs/680kg
Engine	Type No.	Perkins 403D-07
Fuel System	Fuel Type	Gasolion
Fuel System	Fuel Capacity	9gal/35L
Classis	Brake	Hydraulic
	Suspension	Front:Dual A-arm；Rear: Independent (IRS)
	Shock Absorber	Spring Preloaded,Oil Damping
	Rim	Front: AT26X9-14 Rear: AT26X11-14
	Tire Pressure(kpa)	Front:35kPa;Rear: 35kPa
Certificate		EEC/EPA
Color(s) Available		RED,GREEN,WHITE，YELLOW，VISTA CAMO
Optional Equipment		1.Aluminum wheel 2.Painted plastic 3.EPS
Accessories		1.winch 2.bull bar 3.roof 4.front screen(safe glass/PC) 5.rear screen 6.rear protect net(steel)
Loading QTY. of 40'HC		11

Engine

Type No.	Perkins 403D-07
Model	4 Cycle, Inline, water-cooled Diesel
Displacement	762cc
Number of Cylinders	3
Stroke and Bore	67mmX72mm
Compression Ratio	22:01
Max torque and REV	25.3Nm/5000(r/min)
Max Output Power	14kw
Max Speed	40km/h
Start Type	Electric
Ignition Type	ECU
Transmission	CVT

24310 20845
